Descrizione
|
DN |
Ø |
C |
D |
b |
e |
i |
f |
Nr. fori |
|
10 |
3/8˝ |
19 |
90 |
12 |
4 |
60 |
14 |
4 |
|
15 |
1/2˝ |
24 |
95 |
12 |
4 |
65 |
14 |
4 |
|
20 |
3/4˝ |
30 |
105 |
12 |
4 |
75 |
14 |
4 |
|
25 |
1˝ |
36 |
115 |
12 |
4 |
85 |
14 |
4 |
|
32 |
1˝ ¼ |
46 |
140 |
16 |
4 |
100 |
18 |
4 |
|
40 |
1˝ ½ |
54 |
150 |
16 |
4 |
110 |
18 |
4 |
|
50 |
2˝ |
65 |
165 |
16 |
4 |
125 |
18 |
4 |
|
65 |
2˝ ½ |
81 |
185 |
16 |
4 |
145 |
18 |
4 |
|
80 |
3˝ |
94 |
200 |
18 |
5 |
160 |
18 |
8 |
|
100 |
4˝ |
119 |
220 |
18 |
5 |
180 |
18 |
8 |
|
125 |
5˝ |
144 |
250 |
18 |
5 |
210 |
18 |
8 |
|
150 |
6˝ |
173 |
285 |
18 |
5 |
240 |
22 |
8 |
|
200 |
8˝ |
225 |
340 |
20 |
5 |
295 |
22 |
8 |
|
250 |
10˝ |
279 |
395 |
22 |
5 |
350 |
22 |
12 |
|
300 |
12˝ |
329 |
445 |
22 |
5 |
400 |
22 |
12 |
|
400 |
16˝ |
413 |
565 |
25 |
6 |
515 |
26 |
16 |
|
450 |
18˝ |
466 |
615 |
25 |
6 |
565 |
26 |
20 |
